Conductix-Wampfler ProfiDAT compact Mounting Instructions page 64

Mounting Instructions
ProfiDAT compact
®
Data Transmission System
Program 0515
With line feed
Example of segment length "S" (intermediate length "a
ATTENTION!
Fig. 50: Expansion unit dimensioning on segment
Fig. 51: Expansion unit dimensioning on segment
Item Name
A Outfeed
EU Expansion unit
AP Anchor point
X Area without data (1 expansion unit)
MAL0515-0001i-EN
www.conductix.com
" with 1 expansion unit and intermediate length "a
1
Data transfer does not occur in the area of the expansion unit. If there are several
expansion units in a row, the distance between the two antennas must be dimensioned
accordingly!
Item
S
a
1
a
2
Translated from MAL0515-0001k-DE
Name
Segment length
Intermediate length a
1
Intermediate length a
2
" with 2 expansion units)
2
Page 64 of 169
