Connection of client with two antennas
Fig. 143: Client with two antennas
# Name
4 Aircell 5 cable
10 Collector with 316D cable
11 Installation socket
12 Ecoflex 10 cable
14 Client W734
15 Key plug W740
30 ProfiDAT compact line feed
®
31 Terminating resistor
Housing (optional or customer-
50
supplied)
MAL0515-0001i-EN
www.conductix.com
10
11
12
4
C
14
15
HF Connection 1
SMA Connector
N Connector
Installation
N
socket
N Connector
R/SMA Socket
QMA Socket
QMA Connector
Translated from MAL0515-0001k-DE
50
HF Connection 2
180° N Installation socket
180°
180° N Installation socket
90° N Connector
180° R/SMA Socket
180° - -
180°
Length Material Number
180° 1.0 m 3173091
0.6 m 3247347
180° 3187977
180° 3.0 m 3259210
180° 3187873
3187890
- -
3248020
