Mounting Instructions
ProfiDAT
compact
®
Data Transmission System
Program 0515
→ Open/loosen the eccentric tappet (9)
and the adjustment nut (10), to remove
the data rail.
→ Check the distance dimensions (see
Fig. 114).
MAL0515-0001i-EN
www.conductix.com
8
Fig. 112: Remove data rail
Fig. 113: Rail is drilled
Fig. 114: Check distance dimensions
Translated from MAL0515-0001k-DE
9
10
Page 88 of 169
