Mounting Instructions
ProfiDAT compact
®
Data Transmission System
Program 0515
# Name
4 Aircell 5 cable
10 Collector with 316D cable
11 Installation socket
12 Ecoflex 10 cable
14 Client W734
15 Key plug W740
30 ProfiDAT compact line feed
®
31 Terminating resistor
Housing (optional or customer-
50
supplied)
Work steps:
→ Connect the R-SMA connector of the cable (4) to the R-SMA connector of the transceiver. The N-socket on the other end of
the cable (4) must be installed as a switching cabinet bushing and electrically conductively connected to the housing
(grounded).
→ Connect the N-connector of the cable (12) to the cable (11) using the N-connector (10). Connect the N-connector (11),
observe instructions for equipotential bonding, see Section 6.5.3: This N-connector (11) must be installed in an insulated
manner. The N-connector (11) can simultaneously serve as a strain relief for fastening to a tab/strain relief plate.
→ Lead the cable (12) from the collector to the cable (4). Connect the N-connector of the cable (12) to the switching cabinet
bushing N-socket of the cable (4).
→ Fix the cable routing with cable ties or similar to the support structure (substructure); stow excess cables properly.
MAL0515-0001i-EN
www.conductix.com
HF Connection 1
SMA Connector 180°
N Connector 180°
Installation
N 180°
socket
N Connector 90°
R/SMA Socket 180° R/SMA
QMA Socket 180°
QMA Connector 180°
Translated from MAL0515-0001k-DE
HF Connection 2
N Installation socket 180°
N Installation socket 180°
N Connector 180°
Socket 180°
- -
Length Material Number
1.0 m 3173091
0.6 m 3247347
3187977
3.0 m 3259210
3187873
3187890
- -
3248020
