Mounting Instructions
ProfiDAT compact
®
Data Transmission System
Program 0515
4.2 Brief description
The ProfiDAT compact Data Transmission System is a system that facilitates the communication between a stationary network
®
and one or more mobile consumers. The mobile consumers move along the guideway in a linear, track-guided manner. The
collector follows the movement of the mobile consumer and compensates for guideway deviations between the mobile consumer
and the data rail (horizontally and vertically).
The data is coupled with the data rail via the stationary antenna, transmitted to the mobile antenna in the collector head and
forwarded to the mobile consumer via a connecting cable on the collector. The collector head of the collector is pressed against
the data rail with a permanent contact force (approx. 10 N) (for the installation dimension, see Fig. 127).
In addition to the data transfer, the ProfiDAT
positioning system. The positioning system consists of bar code or matrix code band, which is glued to the ProfiDAT
with positioning strip and a read head, which is mounted next to the collector with mobile antenna.
The system is variable in length. It consists of at least one stationary and one mobile transceiver, the stationary antenna and the
mobile antenna. The ProfiDAT
the customer.
TheProfiDAT compact rails are mechanically connected using connectors that ensure stability and the secure connection of the
®
ProfiDAT compact rails. The data is coupled or decoupled of the ProfiDAT
®
data can be continuously received and sent via the mobile antenna.
Examples of applications are:
Electrified monorail systems (EMS)

Logistics shuttles

Packaging machines

Small parts warehouses

MAL0515-0001i-EN
www.conductix.com
compact rail can be simultaneously used as a ground conductor rail and as a
®
compact rails are fastened to the support structure (substructure) using hanger clamps provided by
®
Translated from MAL0515-0001k-DE
compact rails by means of a stationary antenna. The
®
compact rail
®
