Conductix-Wampfler ProfiDAT compact Mounting Instructions page 32

Mounting Instructions
ProfiDAT compact
®
Data Transmission System
Program 0515
Connector types:
Fig. 5 R-SMA angle connector
Fig. 6: QLS connector is unlocked
Fig. 8: N-connector
MAL0515-0001i-EN
www.conductix.com
Fig. 7: QLS connector is locked (green ring visible by pushing the
blue sleeve forward)
Fig. 9: N-socket as switching cabinet bushing on cable
Translated from MAL0515-0001k-DE Page 32 of 169
