Mounting Instructions
ProfiDAT compact
®
Data Transmission System
Program 0515
Procedure for communication disturbances
1. If the fault is persistent:
a) The fault only occurs in one vehicle (client)  carry out a vehicle-related troubleshooting.
If the vehicle-related troubleshooting was not successful, the following components must be checked:
ProfiDAT
o
diagnostic capability of the transceiver.
HF component (cabling, antenna) and equipotential bonding: Check between client and mobile antenna.
o
System layout: General check.
o
Ethernet connection: Check between client and communication device.
o
Communication device (PLC, ...): Check data communication at the protocol level.
o
b) The fault occurs in several or all vehicles (clients) on the same segment (AP)  carry out a route-related
troubleshooting.
If the route-related troubleshooting was not successful, the following components must be checked:
ProfiDAT
o
the diagnostic capability of the transceiver.
ProfiDAT
o
HF components (cabling, antenna) and equipotential bonding: Check between access point and stationary
o
antenna.
System layout: General check.
o
Ethernet connection: Check between access point and communication device.
o
Communication device (PLC, ...): Check data communication at the protocol level.
o
Environment: General check.
o
c) The fault occurs in several vehicles (clients) at different segments (access points)  carry out environment and
analogue-related troubleshooting:
If the environment and analogue-related troubleshooting was not successful, the following components must be
checked:
ProfiDAT
o
capability of the transceiver.
HF component (cabling, antenna) and equipotential bonding: General check.
o
System layout: General check.
o
Ethernet connection: General check.
o
Communication device (PLC, ...): Check data communication at the protocol level.
o
Environment: General check.
o
d) Combined faults from a) to c) occur  A narrowing down is not possible and the entire system must be checked.
MAL0515-0001i-EN
www.conductix.com
compact transceiver (primary diagnostic tool and non-potential fault source): Check client, use the
®
compact transceiver (primary diagnostic tool and non-potential fault source): Check access point, use
®
compact data rail: General check.
®
compact transceiver (primary diagnostic tool and non-potential fault source): Use the diagnostic
®
Translated from MAL0515-0001k-DE Page 146 of 169
