6.2 Preparation
Required tools:
Cross-cut saw

Open-end wrench SW7 (M4)

Open-end wrench SW8 (M5)

Open-end wrench SW13 (M8)

Hexagon screwdriver (Allen key) SW 2.5

Cordless drill driver

Bit attachment hexagon socket (Torx) TX8

Bit attachment hexagon socket plus (Torx Plus) TP10

Round file with ≥ 3 grade of cut

Flat file with ≥ 3 grade of cut

Step drill M3 90°

Drilling jig (Order No.: 05-V015-0005)

Flexible drilling jig (Order No.: 05-V015-0024)

Mounting aid (Order No.: 05-V015-0010)

Torque screwdriver (e.g. Wiha TorqueVario-S 0.1 – 0.6 Nm)

Blade for torque screwdriver, hexagon socket (Torx) T8

Torque shut-off screwdriver (e.g. TorqBee from HS-Technik)

Tools required for replacing sliding contacts:
Torx attachment TX5

Flat-head screwdriver ≤ 3.0

Torque screwdriver (e.g. Wiha TorqueVario-S 0.1 – 0.6 Nm)

Required tools for replacing collector heads:
Torx attachment TX5

Flat-head screwdriver ≤ 3.0

Required material:
Cable ties

