8.3.2 Replacement using the web interface
If there is no removable media or if it is defective, the configuration can also be transmitted using the web interface.
To do this, a backup ("Config" or "ConfigPack") and the firmware of the old transceiver must be available or these must be obtained
by downloading from the old transceiver.
For uploading and downloading "Config", "ConfigPack" and firmware, see 9.3.2.
In order to reach a new transceiver via the web interface, it must first be assigned an IP address. This can be done via a DHCP
server or via Siemens programming software (PRONETA, SINEC PNI, S7 manager, TIA portal).
1. Assign an IP address to the new transceiver.
2. Open the web interface and log in with the default access data (see manufacturer's operating instructions).
3. Load firmware, restart device.
4. Load ConfigPack, restart device.
The device can then be reached under the IP address and the "ConfigPack" access data.
