9.1.4 System layout
Deviations from the project planning of the system layout can lead to malfunctions or completely prevent the successful
commissioning:
a) Section and segment lengths
b) Access point positions
c) HF cable lengths
d) Installation sequence of HF components
e) Use of unsuitable HF components (not supplied by Conductix-Wampfler)
9.1.5 Ethernet cabling
a) Network connection faulty
b) Connected network devices faulty
9.1.6 Communication device
a) Communication parameter faulty
a. Cycle time
b. Packet repetitions
c. Watchdog
See Section 9.4 for a description of the diagnostic options at the protocol level.
9.1.7 Environment
a) Disturbance due to parallel use of the same WLAN channels
b) Disturbance due to wire-bound EM interferences
c) Disturbance due to field-bound EM interferences
