Fig. 82: Maximum offset of connection point in X-direction (direction of travel)
ATTENTION!
Fig. 83: Maximum offset of connection point in Y-direction
MAL0515-0001i-EN
www.conductix.com
max. 0,5 mm
If both rails have an offset of more than 0.5 mm in the Y-direction, then at least one rail
must be replaced!
Max. 0.5 mm
