4.
Collector test – low speed
Test: Travel the entire guideway at 10% of the maximum speed. Observe the activity of the
collector on the data rail, particularly at the rail joints, switches, lifters, joints and other
4.1.
transfers.
Required result: The connections and transfers along the entire length of the data rail are
smooth and the activity of the collector is trouble-free at all times.
Collector test – increased speed
4.2.
Test: Increase the speed to 30 %, 50 %, 80 %, and finally 100 % of the full speed. Successful
result: The collector activity is trouble-free at all times.
Additional functional tests
4.3.
Required result:
All other functions are carried out according to the collector's requirements.
MAL0515-0001i-EN
www.conductix.com
If the configuration of the transceiver has been changed:
These changes are also to be undertaken for all the same/ similar devices of the
•
system.
• These are to be documented and additionally backed up by a ConfigPack – Backup.
Commissioning
