6.4.8 Adjust the length of the ProfiDAT
®
The ProfiDAT compact rails have a standard length of 5 m. Shorter lengths are available, but are usually produced at the
installation site.
2
Fig. 97: Shorten ProfiDAT ®
compact rail
Work steps:
→ Determine the required length of the data rail.
→ The cutting direction (1) must be from the closed rail side.
→ Saw the rails at right angles with the cross-cut saw.
→ Drill holes and countersinks with the step drill M3 90° for connectors using the drilling jig.
→ Deburr all edges in Area A and Area B according to DIN ISO 13715 (Fig. 99).
MAL0515-0001i-EN
www.conductix.com
®
compact rail
The connection points between the ProfiDAT
attenuation of the system. In order for the attenuation to be as low as possible, the rails must
be precisely machined
We therefore recommend that the installation only be carried out by Conductix-Wampfler
personnel.
1
(with positioning strip)
Translated from MAL0515-0001k-DE
compact profiles have a great impact on the
®
and connected at
Fig. 98: Shorten ProfiDAT ®
compact rail
the connection points.
1
2
(without positioning strip)
