8.2.1 Documentation
→ The results of inspections and the measures taken are to be documented in written reports.
→ Conductix-Wampfler must be immediately informed of any defects or malfunctions that occur during the test phase and within
the warranty period.
8.2.2 Maximum wear of the sliding contacts
Wear limit of sliding contacts on ProfiDAT
Fig. 146:
MAL0515-0001i-EN
www.conductix.com
8 mm
max. 5 mm
compact collector
®
