Work steps:
→ Determine the position of the through hole for the line feed in the support structure (substructure) according to Fig. 44 to Fig.
49 centered on the slot of the data rail. ATTENTION: The stationary antenna is located outside (below or above) the center
(see Fig. 46 to Fig. 49).
→ With Ø 25 mm , the through hole is correspondingly large enough for the off-center stationary antenna to fit through the center
through hole in all versions.
→ Drill a through hole D = 25 mm in the support structure (substructure) with, e.g. a hole saw.
→ Position the line feed. Since there is a PE connector at the end of the end feed rail, the steps in Section 6.4.7 must be
followed.
→ Insert the line feed (1) into the hanger clamps (2). Ensure that the hanger clamp grips the rail correctly.
The hanger clamps are elastic and thus allow easy insertion/locking of the rail into the hanger clamp. The rails can be moved
in the hanger clamps.
→ Attention: For applications with built-in expansion units (due to the thermal expansion of the data rail), the through hole must
be designed as an elongated hole to compensate for the movement of the stationary antenna relative to the support structure
(substructure) (see Section 6.4.4).
