Conductix-Wampfler ProfiDAT compact Mounting Instructions page 108

Mounting Instructions
ProfiDAT compact
®
Data Transmission System
Program 0515
# Name
1 Access point W774
2 Key plug W780
3 R-SMA terminating resistor
4 Aircell 5 cable
5 Attenuator 20dB
5 Attenuator 10dB
5 Attenuator 6dB
5 Attenuator 3dB
6 Ecoflex 10 cable
7 Power splitter
8 K_02252_D cable
30 ProfiDAT compact line feed
®
31 Terminating resistor
Housing (optional or customer-
50
supplied)
Work steps:
→ Connect the R-SMA connector of the cable (4) to the R-SMA connector of the transceiver. The N-socket on the other end of
the cable (4) must be installed as a switching cabinet bushing and electrically conductively connected to the housing
(grounded). The grounding plate (Section 6.5.3, Fig. 101, Pos. 40) with the switching cabinet bushing.
→ If available for a specific project, connect the attenuator (5) to the N-socket of the cable (4). Project-specific attenuators can
also be located on the power splitter (7).
→ Connect the N-connector of the cable (6) to the N-socket of the attenuator (5) or the switching cabinet bushing N-socket of the
cable (4).
→ Connect the N-connector of the cable (6) to the cable (8) using the N-connector (11). Fasten the N-connector and follow the
instructions for equipotential bonding, see Section 6.5.3.
→ Lead the QLS connector of the cable (8) to the line feed (30).
→ Connect the QLS connector of the cable (8) to the QMA socket of the line feed (30).
→ Fix the cable routing with cable ties or similar to the support structure (substructure); stow excess cables properly.
→ Connect the QMA terminating resistor (31) to the segment end (30).
MAL0515-0001i-EN
www.conductix.com
HF Connection 1
R/SMA Socket 180° R/SMA
R/SMA Connector 180°
SMA Connector 180°
N Connector 180°
N Connector 180°
N Connector 180°
N Connector 180°
N Connector 180°
N Connector 180°
QLS Connector 90°
QMA Socket 180°
QMA Connector 180°
Translated from MAL0515-0001k-DE
HF Connection 2
Socket 180°
N Installation socket 180°
N Socket 180°
N Socket 180°
N Socket 180°
N Socket 180°
N Connector 180° 10.0 m
N Connector 90°
- -
Length Material Number
3187868
3187889
3170540
1.0 m 3173091
3275950
3275971
3275972
3275973
3173096
3187905
1.0 m 3272896
- -
3248020
Page 108 of 169
-
