Mounting Instructions
ProfiDAT compact
®
Data Transmission System
Program 0515
Data rail material: Aluminium with a 0.0000234 1/K linear expansion coefficient
∆t tot = ∆tU + ∆tSW
∆tU = Temperature range of the ambient temperature [° C]
∆tSW = Temperature increase due to current heat [° C]
Because the ProfiDAT compact may only be used as PE and not as PH rail, the value for ∆tSW always corresponds to 0°.
®
∆t tot = ∆tU
