6.5.6 Connect transceivers to the network
→ Insert the Ethernet connector (RJ45) into the socket P1 (option 1) on the transceiver. Observe the information and safety
instructions in the manufacturer's documentation.
ATTENTION!
ATTENTION!
MAL0515-0001i-EN
www.conductix.com
Instructions regarding the network integration of ProfiDAT(R)compact are described in
TI0514-0001!
See manufacturer's documentation for differences between the two Ethernet ports of
the transceiver.
