6.4.15 Check the installation through attenuation measurement
In order to check the quality of the mechanical installation, the attenuation of the rail can be measured with suitable measuring
means. This measurement can be carried out by the "International Service" of Conductix-Wampfler GmbH.
The expected values for this measurement for each ProfiDAT compact segment are part of the project-specific documentation.
®
Exceeding the expected values indicates a defective mechanical mounting of ProfiDAT compact and must be corrected.
®
