Saving and naming the recording:
Each generated signal scan should be documented with information on the route, time and, if necessary, configuration
characteristics (see Section 9.3.2).
Note: Up to Firmware v6.5.0, the scaling of the displayed attenuation values in the signal scan is incorrect. The measured values
are only correct when the file is downloaded (PDF, CSV).
9.4 Diagnosis by monitoring data traffic with external devices
For a detailed fault analysis, the transmitted protocols can be viewed with specific software and hardware tools. An overview is
below.
- Protocol independent analyses:
Customer control fault memory
o
Recording of Ethernet packets (e.g. via mirror port on connection to customer control)
o
- Protocol-dependent analyses:
Profinet: Profinet Inspector
o
