→ The data cable connector (2) must audibly click into the circuit board connector (3) (see Fig. 167).
Fig. 167: Click in connector
→ Mount the collector housing (1) and balance (2). Carefully tighten the data cable (see Fig. 168).
1
2
Fig. 168: Collector housing (1) is mounted on balance (2)
