6.4.4 Expansion unit
6.4.4.1 Expansion unit layout
Number of expansion units per segment:
The maximum segment length for a line feed (center) is 120 meters. The maximum segment length is linked to the data
transmission and not to the ProfiDAT
Segment length with 1 stationary access point and 1 mobile participant (client): max. 120 meters (2 x 60 meters)
1 mobile participant (client) corresponds to a maximum of 2 mobile antennas.
Segment length with 1 stationary access point and 6 to 20 mobile participants (clients): Max. 100 meters (2 x 50 meters)
1 mobile participant (client) corresponds to a maximum of 2 mobile antennas.
Due to the geometry of the line feed and outfeed, an anchor point "AP" is created both in the middle of the route and at the ends of
a segment "S".
This means that the intermediate length corresponds to "a" = "S/2".
Number of Expansion Units (EU)
Length
Number of mobile participants
(clients)
10°
15°
20°
25°
30°
35°
40°
45°
50°
MAL0515-0001i-EN
www.conductix.com
compact rail made of aluminium in particular.
®
1
1
6 – 20 mobile
Mobile
participants
participant
(clients)
(client)
60 m 50 m
60 m 50 m
50 m 50 m
40 m 40 m
30 m 30 m
35 m 35 m
25 m 25 m
20 m 20 m
20 m 20 m
Translated from MAL0515-0001k-DE
2
Intermediate Length "a"
1
6 – 20 mobile
Mobile
participants
participant
(clients)
(client)
60 m
60 m 50 m
60 m 50 m
60 m 50 m
50 m 50 m
45 m 45 m
40 m 40 m
3
1
6 – 20 mobile
Mobile
participants
participant
(clients)
(client)
60 m
60 m 50 m
60 m 50 m
