9 Data Transmission Troubleshooting
WARNING!
ATTENTION!
Troubleshooting for the data transmission is possible using various approaches.
ATTENTION!
The troubleshooting procedure is significantly influenced by the system, so the troubleshooting approach must be selected on the
basis of the individual system.
The primary tools for data transmission troubleshooting are integrated into the WLAN transceiver:
Section "9.2 Diagnosis via the transceiver LED state"
•
Section "9.3 Diagnosis via the transceiver web interface"
•
Secondarily, monitoring the data traffic at the protocol level can provide useful information about the source of the fault, e.g.:
- Which transmission protocol is disturbed?
- Is an individual vehicle disturbed or are several vehicles disturbed?
- Are there recurring patterns in which the disturbances occur, e.g. only at one of several WLAN access points?
For this, see Section 9.4 for a systematic approach in the event of a system disturbance.
MAL0515-0001i-EN
www.conductix.com
Risk of injury due to improper fault correction!
Improper fault correction can result in serious injury to persons or material damage.
→ Contact the manufacturer in case of failures.
→ Only allow fault correction to be conducted by personnel from or authorized by the
manufacturer.
In case of frequently occurring PROFINET faults:
→ Check the mechanical system.
Ensure that the data transfer rate to the ProfiDAT
specified limit (see page 24).
Observe the manufacturer's operating instructions!
The following sections provide a rough overview. They are not intended to replace the
operating instructions and project planning documents of the transceiver manufacturer.
Translated from MAL0515-0001k-DE
®
compact system does not exceed the
