Mounting Instructions
ProfiDAT compact
®
Data Transmission System
Program 0515
2.
The ProfiDAT
The stationary ProfiDAT
Switch on the 24 V power supply to the ProfiDAT
DAT compact transceiver at least 1 minute to start.
®
Requirement:
2.1.
LED "L1" or "L2" or "PoE" lights up green.
LED "R1" lights up green or flashes green to orange.
LED "P1" and/or "P2" light up green or flash green to orange.
LED "F" is off.
The ProfiDAT compact transceiver on the vehicle is turned on and the LAN is
®
connected.
Switch on the 24 V power supply to the ProfiDAT
ProfiDAT compact transceiver at least 1 minute to start.
®
Requirement:
2.2.
LED "L1" or "L2" or "PoE" lights up green.
LED "R1" lights up green or flashes green to orange.
LED "P1" and/or "P2" light up green or flash green to orange.
LED "F" is off.
The ProfiDAT compact connection is established
®
Requirement:
2.3.
LED "R1" lights up green or flashes green to orange.
3.
3.1. All access points are accessible from a central point via the network.
3.2.
All clients are connected to the respective access point (see Section 9.3.8).
When using two mobile collectors per client: Both mobile collector of a vehicle receive a
3.3.
similar* signal strength (see Section 9.3.10)
3.4.
All vehicles receive the same signal strength at a reference position (e.g. line feed)
A signal scan with one vehicle throughout the entire route was carried out and is trouble-free
3.5.
and without deviation at a normal operating speed (see Section 9.3.11)
MAL0515-0001i-EN
www.conductix.com
®
compact connection has been confirmed via device LEDs
compact transceiver is turned on and the LAN is connected.
®
compact transceiver and allow the Profi-
®
The initial commissioning of the transceiver must occur simultaneously with the
commissioning of the system into which the data transmission system is integrated. The
connection establishment and the data transmission can only take place when the system is
turned on and a connection is established between the antenna on the collector and the
stationary antenna on the line feed via the ProfiDAT
Initial commissioning of data transmission
Translated from MAL0515-0001k-DE
compact transceiver and allow the
®
compact rail.
®
