Mounting Instructions
ProfiDAT
compact
®
Data Transmission System
Program 0515
→ Mount new balance incl. sliding contact (1) on the joint of the collector arm (2) (see Fig. 177)
1
2
Fig. 177: Balance incl. sliding contact (1) is mounted
→ The balance must audibly click twice over the lateral bolts (see Fig. 178).
Fig. 178: Balance clicks audibly
MAL0515-0001i-EN
www.conductix.com
Translated from MAL0515-0001k-DE
Page 136 of 169
