Tightening torques:
Connector type
N
(R)-SMA
ATTENTION!
ATTENTION!
MAL0515-0001i-EN
www.conductix.com
QLS connectors are not screwed, but rather are locked by pushing the blue sleeve
forward (green ring becomes visible). To remove the connector, the blue sleeve must
be pulled back (unlocked) in the direction of the cable.
N-connectors can easily tilt. Ensure that the thread is not destroyed when attaching the
connector.
Translated from MAL0515-0001k-DE
Tightening torque
4 to 6 Nm
0.79 to 1.13 Nm
