Intermediate circuit voltage
Intermediate circuit voltage /
Peak value
Output voltage
4.3.5 Basic Adjustment
of the Drive
Speed control / Configuration
Chapter Section Page
4 3 8
Display of actual DC-link voltage in volt.
Typical calues:
V-class normal operation
230 V 300Ö330 V DC
400 V 530Ö620 V DC
CP.8 makes it possible to recognize short-time voltage rises within an operating cycle.
For that the highest value of CP.7 is stored in CP.8. The peak value memory can be
cleared by pressing the UP, DOWN or ENTER key or over bus by writing any value
you like to the address of CP.8. The switch off of the inverter also clears the memory.
Display of the actual output voltage in volt.
The following parameters determine the fundamental operating data of the drive and
must be adjusted for the initial commissioning (see chapter 4 ÑStart-upì). They should
be checked and/or adapted to the application.
With this parameter the basic setting of the speed controller is determined.
Value Function
0 off (controlled operation)
1 -reserved-
2 -reserved-
3 off (controlled operation)
4 Speed control (regulated operation)
5 Torque control (regulated operation)
Adjustment range:
Resolution:
Factory setting:
Date Name: Basis
17.05.04 KEB COMBIVERT F5-M / S
over voltage (E.OP)
ca. 400 V DC
ca. 800 V DC
F5-M: 0(off)...63 / F5-S: 4...5
F5-M: 0 (off) / F5-S: 4
©
CP - Parameter
under voltage (E.UP)
ca. 216 V DC
ca. 240 V DC
1
