Combined buffers for central heating and domestic hot water production | 93
I. Intended use
The appliance is intended to supply hot wa-
ter to households equipped with a piping
system working at pressure below 8 bar (0,8
MPa), as well as for mounting into central
heating system with pressure below 0.3
MPa (3 Bar).
The appliance is intended for work in closed,
heated premises (above 4 oC).
II. Description and technical
data
Depending on the model of the high ca-
pacity water heater (HCWH), it can has
one or two built-in heat exchangers.
connections to the high capacity buff-
ers should be made following the mar-
ket outlets and inlets, described below:
TS1, TS2, TS3, ТSS1,TSS2 - for mounting
temperature sensors (each heat exchanger
can be controlled by temperature). If the ap-
pliance is equipped with one heat exchanger
there will be only one outlet "TS1" available.

Data plate

The data plate is located at the top of the
rear of the DHW cylinder and includes the
following details:
Pos. Description
1
Model designation
2
Serial number
3
Actual content
4
Standby heat loss
5
Volume heated by immersion heater
6
Year of manufacture
7
Corrosion protection
8
Max. DHW cylinder temperature
9
Max. flow temperature, heat source
10
Max. flow temperature, solar
11
Connected electrical load
12
Heating water heat input
The
13
Heating water throughput for heating water heat
input
14
With 40 °C drawable volume, heated electrically
15
Max. operating pressure, DHW side
16
Highest design pressure
17
Max. operating pressure, heat source side
18
Max. operating pressure, solar side
19
Max. operating pressure, DHW side, CH
20
Max. test pressure, DHW side, CH
21
Max. DHW temperature with electric heating
