MDDR Subsystem
Table 56 • DDRC_ADDR_MAP_COL_3_CR (continued)
Bit
Numbe
r Name
4 REG_DDRC_DIS_ACT_BYPASS
3 REG_DDRC_DIS_RD_BYPASS
2 REG_DDRC_DIS_PRE_BYPASS
1 REG_DDRC_DIS_COLLISION_PAGE_OP
T
0 Reserved
Table 57 • DDRC_MODE_REG_RD_WR_CR
Bit
Number Name
[31:4] Reserved
3 REG_DDRC_MR_WR
[2:1] REG_DDRC_MR_ADDR
0 REG_DDRC_MR_TYPE
Table 58 • DDRC_MODE_REG_DATA_CR
Bit
Number Name
Reset
Value Description
0×0
0×0
0×0
0×0
0×0
Reset
Value Description
0×0 Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0×0 When 1 is written and DDRC_REG_MR_WR_BUSY is Low, a mode
register read or write operation is started. There is no need for the CPU
to set this back to zero. This bit always reads as zero.
0×0 Address of the Mode register that is to be written to.
00: MR0
01: MR1
10: MR2
11: MR3
0×0 Indicates whether the Mode register operation is read or write.
1: Read
0: Write
Reset
Value Description
Microsemi Proprietary UG0446 User Guide Revision 7.0
Only present in designs supporting activate bypass.
When 1, disable bypass path for high priority read
activates
Only present in designs supporting read bypass.
When 1, disable bypass path for high priority read page
hits.
Only present in designs supporting precharge bypass.
When 1, disable bypass path for high priority
precharges
When this is set to '0', auto-precharge is disabled for
the flushed command in a collision case. Collision
cases are write followed by read to same address, read
followed by write to same address, or write followed by
write to same address with REG_DDRC_DIS_WC bit =
1 (where same address comparisons exclude the two
address bits representing the critical word).
Software should not rely on the value of a reserved bit.
To provide compatibility with future products, the value
of a reserved bit should be preserved across a read-
modify-write operation.
81
