MDDR Subsystem
Table 33 • DDRC_MODE_CR
7 REG_DDRC_MOBILE
6 REG_DDRC_SDRAM
5 REG_DDRC_TEST_MODE
[4:2] REG_DDRC_MODE
[1:0] REG_DDRC_DATA_BUS_WIDTH
Table 34 • DDRC_ADDR_MAP_BANK_CR
Bit
Number Name
[31:12] Reserved
[11:8] REG_DDRC_ADDRMAP_BANK_B0
[7:4] REG_DDRC_ADDRMAP_BANK_B1
[3:0] REG_DDRC_ADDRMAP_BANK_B2
0×0 1: Mobile/LPDDR1 DRAM device in use
0: Non-mobile DRAM device in use
0×0 1: SDRAM mode
0: Non-SDRAM mode. Only present in designs that support
SDRAM and/or mSDR devices.
0×0 1: Controller is in test mode
0: Controller is in normal mode
0×0 DRAM SECDED mode
000: No SECDED
101: SECDED enabled
All other selections are reserved.
0×0 00: Full DQ bus width to DRAM
01: Half DQ bus width to DRAM
10: Quarter DQ bus width to DRAM
11: Reserved
Reset
Value Description
0×0
0×0
0×0
0×0
Microsemi Proprietary UG0446 User Guide Revision 7.0
Note: The half bus width modes are only supported
when the DRAM bus width is a multiple of 16.
Software should not rely on the value of a reserved bit. To
provide compatibility with future products, the value of a
reserved bit should be preserved across a read-modify-
write operation.
Selects the address bits used as bank address bit 0. Valid
Range: 0 to 14
Internal Base: 2
The selected address bit for each of the bank address bits
is determined by adding the internal base to the value of
this field.
Selects the address bits used as bank address bit 1. Valid
Range: 0 to 14
Internal Base: 3
The selected address bit for each of the bank address bits
is determined by adding the internal base to the value of
this field.
Selects the address bits used as bank address bit 2. Valid
Range: 0 to 14 and 15
Internal Base: 4
The selected address bit is determined by adding the
internal base to the value of this field. If set to 15, bank
address bit 2 is set to 0.
69
