Fabric DDR Subsystem
Table 152 • FDDR_IO_CALIB
13 CALIB_LOCK
12 CALIB_START
[11:6] NCODE
[5:0] PCODE
Table 153 • FDDR_INTERRUPT_ENABLE
Bit
Number Name
[31:7] Reserved
6 DDR_FIC_INT_ENABLE
5 IO_CALIB_INT_ENABLE
4 FDDR_ECC_INT_ENABLE
3 FABRIC_PLL_LOCKLOST_INT_ENABLE
2 FABRIC_PLL_LOCK_INT_ENABLE
1 FPLL_LOCKLOST_INT_ENABLE
0 FPLL_LOCK_INT_ENABLE
Table 154 • F_AXI_AHB_MODE_SEL
Bit Name
Number
[31:1] Reserved
0 F_AXI_AHB_MODE
0×0
0×0
0×0
0×0
Reset
Value
0×0
0×0
0×0
0×0
0×0
0×0
0×0
0×0
Reset
Value
0×0 Software should not rely on the value of a reserved bit. To
provide compatibility with future products, the value of a
reserved bit should be preserved across a read-modify-write
operation.
0×0 1: AXI interface in the fabric will be selected.
0: AHB interface in the fabric will be selected.
Microsemi ProprietaryUG0446 User Guide Revision 7.0
Used in the DDRIO calibration block as an override
to lock the codes during intermediate runs. When
the firmware receives CALIB_INTRPT, it may
choose to assert this signal by prior knowledge of
the traffic without going through the process of
putting the DDR into self refresh.
Indicates that rerun of the calibration state machine
is required in the DDRIO calibration block.
Indicates the DPC override NCODE from flash in
DDRIO calibration. This can also be overwritten
from the firmware.
Indicates the PC override PCODE from flash in the
DDRIO calibration block. This is also be overwritten
from the firmware.
Description
Software should not rely on the value of a reserved
bit. To provide compatibility with future products, the
value of a reserved bit should be preserved across a
read-modify-write operation.
Masking bit to enable DDR_FIC interrupt
Masking bit to enable DDR I/O calibration interrupt
Masking bit to enable ECC error interrupt
Masking bit to enable FAB_PLL_LOCK_LOST
interrupt
Masking bit to enable FAB_PLL_LOCK interrupt
Masking bit to enable FPLL_LOCK_LOST interrupt
Masking bit to enable FPLL_LOCK interrupt
Description
