MDDR Subsystem
3
MDDR Subsystem
The MDDR is a hardened ASIC block for interfacing the DDR2, DDR3, and LPDDR1 memories. The
MDDR subsystem is used to access DDR memories for high-speed data transfers and code execution.,
and includes a DDR memory controller, DDR PHY, and arbitration logic to support multiple masters. DDR
memory connected to the MDDR subsystem can be accessed by the MSS/HPMS masters and master
logic implemented in the FPGA fabric (FPGA fabric master).
The MSS/HPMS masters communicate with the MDDR subsystem through an MSS/HPMS DDR bridge
that provides an efficient access path. FPGA fabric masters communicate with the MDDR subsystem
through AXI or AHB interfaces.
3.1
Features
•
Integrated on-chip DDR memory controller and PHY
•
Capable of supporting LPDDR1, DDR2, and DDR3 memory devices
•
Up to 667 Mbps (333.33 MHz DDR) performance
•
Supports memory densities upto 4GB
•
Supports 8/16/32-bit DDR standard dynamic random access memory (SDRAM) data bus width
modes
•
Supports a maximum of 8 memory banks
•
Supports single rank memory
•
Single error correction and double error detection (SECDED) enable/disable feature
•
Supports DRAM burst lengths of 4, 8, or 16, depending on the bus-width mode and DDR type
configuration
•
Support for sequential and interleaved burst ordering
•
Programs internal control for ZQ short calibration cycles for DDR3 configurations
•
Supports dynamic scheduling to optimize bandwidth and latency
•
Supports self refresh entry and exit on command
•
Supports deep power-down entry and exit on command
•
Flexible address mapper logic to allow application specific mapping of row, column, bank, and rank
bits
•
Configurable support for 1T or 2T timing on the DDR SDRAM control signals
•
Supports autonomous DRAM power-down entry and exit caused by lack of transaction arrival for
programmable time
The following illustration shows the system level block diagram of the MDDR subsystem.
Microsemi Proprietary UG0446 User Guide Revision 7.0
