MDDR Subsystem
Table 109 • DDR_FIC_HPD_SW_RW_INVAL_CR (continued)
Bit
Number Name
3 Reserved
2 DDR_FIC_flshM2
1 Reserved
0 DDR_FIC_invalid_M2
Table 110 • DDR_FIC_SW_WR_ERCLR_CR
Bit
Number Name
[31:9] Reserved
8 DDR_FIC_LTO_CLR
[7:5] Reserved
4 DDR_FIC_M2_WR_ERCLR
[3:1] Reserved
0 DDR_FIC_M1_WR_ERCLR
Table 111 • DDR_FIC_ERR_INT_ENABLE
Bit
Number Name
[31:2] Reserved
Reset
Value Description
0×0 Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0×0 1: Flush write buffer for AHBL master2.
0: Default
0×0 Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0×0 1: Invalidate read buffer for AHBL master2.
0: Default
Reset
Value Description
0×0 Software should not rely on the value of a reserved bit. To
provide compatibility with future products, the value of a
reserved bit should be preserved across a read-modify-write
operation.
0×0 Clear signal to lock timeout interrupt.
0×0 Software should not rely on the value of a reserved bit. To
provide compatibility with future products, the value of a
reserved bit should be preserved across a read-modify-write
operation.
0×0 Clear bit for error status of AHBL master2 write buffer. Once it
goes High, error status is cleared.
0×0 Software should not rely on the value of a reserved bit. To
provide compatibility with future products, the value of a
reserved bit should be preserved across a read-modify-write
operation.
0×0 Clear bit for error status posted by AHBL master1 write buffer.
Once it goes High, error status is cleared.
Reset
Value Description
0×0 Software should not rely on the value of a reserved bit. To
provide compatibility with future products, the value of a
reserved bit should be preserved across a read-modify-write
operation.
