MDDR Subsystem
Table 28 • DDR Controller Configuration Register (continued)
Register Name
DDRC_WR_QUEUE_PARAM_CR
DDRC_PERF_PARAM_2_CR
DDRC_PERF_PARAM_3_CR
DDRC_DFI_RDDATA_EN_CR
DDRC_DFI_MIN_CTRLUPD_TIMING_CR
DDRC_DFI_MAX_CTRLUPD_TIMING_CR
Reserved
Reserved
Reserved
Reserved
Reserved
DDRC_DYN_SOFT_RESET_ALIAS_CR
DDRC_AXI_FABRIC_PRI_ID_CR
DDRC_SR
SECDED Registers
DDRC_SINGLE_ERR_CNT_STATUS_SR
DDRC_DOUBLE_ERR_CNT_STATUS_SR
DDRC_LUE_SYNDROME_1_SR
DDRC_LUE_SYNDROME_2_SR
DDRC_LUE_SYNDROME_3_SR
DDRC_LUE_SYNDROME_4_SR
DDRC_LUE_SYNDROME_5_SR
DDRC_LUE_ADDRESS_1_SR
DDRC_LUE_ADDRESS_2_SR
DDRC_LCE_SYNDROME_1_SR
Addres
s Offset
0×0B0
0×0B4
0×0B8
0×0BC
0×0C0
0×0C4
-
-
-
-
-
0×0DC
0×0E0
0×0E4
0×0E8
0×0EC
0×0F0
0×0F4
0×0F8
0×0FC
0×100
0×104
0×108
0×10C
Microsemi Proprietary UG0446 User Guide Revision 7.0
Registe Reset
r Type Source Description
RW PRESET_N DDRC Performance
Parameter register
RW PRESET_N DDRC Performance
Parameter register
RW PRESET_N DDRC Performance
Parameter register
RW PRESET_N DDRC DFI Read Command
Timing register
RW PRESET_N DDRC DFI Controller
Update Min Time register
RW PRESET_N DDRC DFI Controller
Update Max Time register
- - -
- - -
- - -
- - -
- - -
RW PRESET_N DDRC reset register
RW PRESET_N DDRC AXI Interface Fabric
Priority ID Register
RO PRESET_N DDRC Status register
RO PRESET_N DDRC single error count
Status register
RO PRESET_N DDRC double error count
status register
RO PRESET_N DDRC last uncorrected
error syndrome register
RO PRESET_N DDRC last uncorrected
error syndrome register
RO PRESET_N DDRC last uncorrected
error syndrome register
RO PRESET_N DDRC last uncorrected
error syndrome register
RO PRESET_N DDRC last uncorrected
error syndrome register
RO PRESET_N DDRC last uncorrected
error address register
RO PRESET_N DDRC last uncorrected
error address register
RO PRESET_N DDRC last corrected error
syndrome register
