Soft Memory Controller Fabric Interface Controller
Table 166 • SMC_FIC 64-bit AXI Port List (continued)
Signal
MDDR_SMC_AXI_M_ARLOCK[1:0]
MDDR_SMC_AXI_M_BID[3:0]
MDDR_SMC_AXI_M_RID[3:0]
MDDR_SMC_AXI_M_RRESP[1:0]
MDDR_SMC_AXI_M_BRESP[1:0]
MDDR_SMC_AXI_M_RDATA[63:0]
Table 167 • SMC_FIC 32-bit AHB-Lite Port List
Signal
MDDR_SMC_AHB_M_HMASTLOCK
MDDR_SMC_AHB_M_HWRITE
MDDR_SMC_AHB_M_HRESP
MDDR_SMC_AHB_M_HREADY
MDDR_SMC_AHB_M_HBURST[1:0]
MDDR_SMC_AHB_M_HTRANS[1:0]
Direction Polarity Description
Output
Input
Input
Input
Input
Input
Direction Polarity Description
Output High
Output High
Input High
Input High
Output
Output
Microsemi Proprietary UG0446 User Guide Revision 7.0
Indicates lock type. This signal provides additional
information about the atomic characteristics of the read
transfer.
00: Normal access
01: Exclusive access
10: Locked access
11: Reserved
Indicates response ID. The identification tag of the write
response. The MDDR_SMC_AXI_M_BID value must
match the MDDR_SMC_AXI_M_AWID value of the
write transaction to which the slave is responding.
Read ID tag. This signal is the ID tag of the read data
group of signals. The MDDR_SMC_AXI_M_RID value
is generated by the slave and must match the
MDDR_SMC_AXI_M_ARID value of the read
transaction to which it is responding.
Indicates read response. This signal indicates the
status of the read transfer.
00: Normal access okay
01: Exclusive access okay
10: Slave error
11: Decode error
Indicates write response. This signal indicates the
status of the write transaction.
00: Normal access okay
01: Exclusive access okay
10: Slave error
11: Decode error
Indicates read data.
Indicates that the current master is performing a locked
sequence of transfers.
Indicates write control signal. When High, this signal
indicates a write transfer, and when Low, a read
transfer.
The transfer response indicates the status of transfer.
When High, the signal indicates that a transfer has
been completed on the bus. This signal may be driven
Low to extend a transfer.
Indicates the burst type.
Indicates the type of the current transfer.
00: Idle
01: Busy
10: Non-sequential
11: Sequential
224
