Fabric DDR Subsystem
Table 130 • FDDR AHB Slave Interface Signals (continued)
Signal Name
AHBx_S_HTRANS[1:0]
AHBx_S_HMASTLOCK
AHBx_S_HWRITE
AHBx_S_HREADY
AHBx_S_HWDATA[31:0] Input
Note: AHBx indicates AHB0 or AHB1.
4.5.2.3 APB Slave
The following table describes the FDDR APB slave interface signals. For APB protocol details, refer to
AMBA APB v3.0 protocol
Table 131 • FDDR APB Slave Interface Signals
Signal Name
APB_S_PREADY
APB_S_PSLVERR
APB_S_PRDATA[15:0]
APB_S_PENABLE
APB_S_PSEL
APB_S_PWRITE
APB_S_PADDR[10:2]
APB_S_PWDATA[15:0]
4.6

Initialization

After power-up, the FDDR needs to have all of the configuration registers written to establish the
operating modes of the blocks. When using the System Builder design flow through Libero SoC, this is
all handled for the user through the use of the System Builder module. All of the configuration register
values are selected by the user and stored in a special portion of the eNVM. Before the FDDR
subsystem is active, it goes through an initialization phase and this process starts with a reset sequence.
For DDR3 memories, the initialization phase also includes ZQ calibration and DRAM training.
4.6.1

Reset Sequence

The following illustration shows the required reset sequence for FDDR subsystem from the power-on-
reset stage. The CORE_RESET_N signal of the FDDR subsystem must be asserted after
MSS_RESET_N_M2F/ HPMS_RESET_N_M2F and FDDR FPLL lock go High and APB register
configuration is complete. Assertion of CORE_RESET_N signifies the end of the reset sequence. The
DDR controller performs external DRAM memory reset and initialization as per the JEDEC specification,
including reset, refresh, and mode registers.
Direction Polarity Description
Input Indicates AHB transfer type from Fabric master.
00: IDLE
01: BUSY
10: NONSEQUENTIAL
11: SEQUENTIAL
Input High Indicates AHB master lock signal from Fabric master.
Input High Indicates AHB write control signal from Fabric master.
Input High Indicates that a transfer has finished on the bus. Fabric master
can drive this signal LOW to extend a transfer.
Indicates AHB write data from Fabric master.
specification.
Direction Polarity Description
Output High Indicates APB Ready signal to Fabric master.
Output High Indicates error condition on an APB transfer to Fabric master.
Output Indicates APB read data to Fabric master.
Input High Indicates APB enable from Fabric master. The enable signal is used
to indicate the second cycle of an APB transfer.
Input High Indicates APB slave select signal from Fabric master
Input High Indicates APB write control signal form Fabric master
Input Indicates APB address initiated by Fabric master.
Input Indicates APB write data from Fabric master.
