MDDR Subsystem
Table 74 • DDRC_DFI_MIN_CTRLUPD_TIMING_CR
Bit
Number Name
[31:10] Reserved
[9:0] REG_DDRC_DFI_T_CTRLUP_MIN
Table 75 • DDRC_DFI_MAX_CTRLUPD_TIMING_CR
Bit
Number Name
[31:10] Reserved
[9:0] REG_DDRC_DFI_T_CTRLUP_MAX
Table 76 • DDRC_DYN_SOFT_RESET_ALIAS_CR
Bit
Number Name
[31:3] Reserved
2 AXIRESET
Microsemi Proprietary UG0446 User Guide Revision 7.0
Reset
Value Description
0×0 Software should not rely on the value of a
reserved bit. To provide compatibility with future
products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0×03 Specifies the minimum number of clock cycles
that the DDRC_DFI_CTRLUPD_REQ signal
must be asserted. Lowest value to assign to this
variable is 0x3. Units: Clocks
Reset
Value Description
0×0 Software should not rely on the value of a
reserved bit. To provide compatibility with future
products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0×40 Specifies the maximum number of clock cycles
that the DDRC_DFI_CTRLUPD_REQ signal can
assert. Lowest value to assign to this variable is
0x40. Units: Clocks
Reset
Value Description
0×0 Software should not rely on the value
of a reserved bit. To provide
compatibility with future products, the
value of a reserved bit should be
preserved across a read-modify-write
operation.
0×1 Set when main AXI reset signal is
asserted. Reads and writes to the
dynamic registers should not be
carried out. This is a read only bit.
