MDDR Subsystem
Table 117 • DDR_FIC_HPD_SW_WRB_EMPTY_SR
Bit
Number Name
[31:7] Reserved
6 DDR_FIC_M1_RBEMPTY
5 Reserved
4 DDR_FIC_M1_WBEMPTY 0×0
3 Reserved
2 DDR_FIC_M2_RBEMPTY
1 Reserved
0 DDR_FIC_M2_WBEMPTY 0×0
Table 118 • DDR_FIC_SW_HPB_LOCKOUT_SR
Bit
Number Name
[31:9] Reserved
[7]
[5]
[3]
[1]
8 DDR_FIC_LCKTOUT
6 DDR_FIC_M2_WDSBL_DN
4 DDR_FIC_M2_RDSBL_DN
2 DDR_FIC_M1_WDSBL_DN
0 DDR_FIC_M1_RDSBL_DN
Reset
Value Description
0×0 Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit
should be preserved across a read-modify-write operation.
0×0 1: Read buffer of AHBL master1 does not have valid data.
0×0 Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit
should be preserved across a read-modify-write operation.
1: Write buffer of AHBL master1 does not have valid data.
0: Default
0×0 Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit
should be preserved across a read-modify-write operation.
0×0 1: Read buffer of AHBL master2 does not have valid data.
0: Default.
0×0 Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit
should be preserved across a read-modify-write operation.
1: Write buffer of AHBL master2 does not have valid data.
0: Default
Reset
Value Description
0×0 Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit
should be preserved across a read-modify-write operation.
0×0 Indicates lock counter in arbiter reached its maximum value.
Lock counter (20-bit) starts counting when a locked request gets
access to a bus and will be cleared when the lock signal becomes
logic 0.
0×0 High indicates AHBL master2 write buffer is disabled.
0×0 High indicates AHBL master2 read buffer is disabled.
0×0 High indicates AHBL master1 read buffer is disabled.
0×0 High indicates AHBL master1 write buffer is disabled.
