Configuration of Job Flow Sheets

This section describes how to configure the machine to use the Job Flow Sheets service.

Step 1 Enabling Ports and Setting up TCP/IP........................................................................................................................597

Step 2 Configuring the SNMP Port...........................................................................................................................................598
Step 3 Configuration on the Computer ..................................................................................................................................598
Step 1 Enabling Ports and Setting up TCP/IP
To use the Job Flow Sheets service, enable the SOAP, SNMP, and Internet Services (HTTP)
ports, and set an IP address and other addresses. The following describes the configuration
procedures on the machine.
Note
1
Display the [Tools] screen.
1) Press the <Log In/Out> button.
2) Enter the system administrator's user ID with the numeric keypad or the keyboard
displayed on the screen, and select [Enter].
When a passcode is required, select [Next] and enter the system administrator's
passcode, and select [Enter].
Note
3) Select [Tools] on the Services Home screen.
2
Enable the SOAP port.
1) Select [Connectivity & Network Setup].
2) Select [Port Settings].
3) Select [SOAP], and then select [Change Settings].
4) Select [Port Status], and then select [Change Settings].
5) Select [Enabled], and then select [Save].
6) Select [Close] repeatedly until the [Port Settings] screen is displayed.
3
Enable the SNMP port.
1) Select [SNMP], and then select [Change Settings].
2) Select [Port Status], and select [Change Settings].
3) Select [Enabled], and then select [Save].
4) Select [Close] repeatedly until the [Port Settings] screen is displayed.
5) Enable the Internet Services (HTTP) port as described above.
6) Select [Close] repeatedly until the [Tools] screen is displayed.
4
Set an IP address and the other addresses.
Skip this step if an IP address is already set.
If DHCP or BOOTP is available in your environment, configure the method for obtaining the
addresses. If an IP address cannot be obtained automatically or manual configuration is
preferred, confirm the settings of an IP address, a subnet mask, and a gateway address.
For information on how to set an IP address, refer to "Protocol Settings" (P.473).
• You can configure the settings using CentreWare Internet Services. For information on how to use
CentreWare Internet Services, refer to "CentreWare Internet Services Settings" (P.555).
• The default user ID is "11111".
• The default passcode is "x-admin".

Configuration of Job Flow Sheets

17
597
