Basic Remote Networking
The SCS in Seattle must also be able to call Dallas.
IP traffic must be transferred between Seattle and Dallas.
IP users in Dallas must connect to IP network 192.0.1.0 in Seattle. IP users in Seattle must connect to
IP network 192.0.2.0 in Dallas.
Both servers are to be dedicated to this purpose. No other applications are supported.
After 60 seconds of idle time, the connection between Dallas and Seattle should be timed out.
The SCS in Seattle expects the username dallas and the password xyz. The SCS in Dallas expects the
username seattle and the password abc.
This SCS must be configured for incoming and outgoing LAN to LAN connections:
Local>> DEFINE PORT 2 ACCESS DYNAMIC
Local>> DEFINE PORT 2 PPP DEDICATED
Local>> DEFINE PORT 2 MODEM ENABLED
Local>> LIST MODEM
Local>> DEFINE PORT 2 MODEM TYPE 1
Local>> DEFINE PORT 2 MODEM SPEAKER DISABLED
Local>> DEFINE PORT 2 AUTHENTICATE ENABLED
Local>>
Local>> DEFINE SITE SEATTLE AUTHENTICATION USERNAME "dallas"
Local>> DEFINE SITE SEATTLE AUTHENTICATION LOCAL "abc"
Local>> DEFINE SITE SEATTLE AUTHENTICATION REMOTE "xyz"
Local>> DEFINE SITE SEATTLE AUTHENTICATION CHAP
Local>> DEFINE SITE SEATTLE IDLE 60
Local>> DEFINE SITE SEATTLE PORT 2
Local>> DEFINE SITE SEATTLE TELEPHONE 2065551234
Local>>
Local>> DEFINE IP ROUTE 192.0.1.0 SITE SEATTLE 2
Local>> DEFINE IP ROUTING ENABLED
Local>>
Local>> INITIALIZE SERVER DELAY 0
The Initialize Server Delay 0 command will reboot the SCS; when the unit has rebooted, changes made
with the Define commands will be in effect.
Figure 4-37: Dallas SCS Configuration
