Security

11.5.5 Locking a Port

The Lock command may be used to secure a port without disconnecting sessions. When Lock is entered,
the user will be prompted to enter a password. This port will then be locked until this password is used to
unlock it. Figure 11-40 displays an example:
Local> LOCK
Password> donut (not echoed)
Verification> donut (not echoed)
Unlock password> donut (not echoed)
Local>
Secure ports (set using the Set/Define Ports Security command) cannot be
Note:
locked.
To unlock a port without the Lock password, a privileged user must use the Unlock Port command
(discussed on page 12-100) or log out the port using the Logout Port command (discussed on page 12-53).
Logout will disconnect all sessions.

11.5.6 Forcing Execution of Commands

When a username is entered in the local authentication database (NVR), a series of commands may be
associated with that user. These commands will be executed when the user is successfully authenticated.
To execute commands when the user logs into the SCS, first ensure that authentication databases have been
configured; see Database Configuration on page 11-9 for instructions. Then associate commands with the
username using the Set/Define Authentication User Command command. The commands you specify
will be executed when the user is successfully authenticated.
Local>> DEFINE AUTHENTICATION USER bob COMMAND "SET PPP dialin_users; logout"
In the previous example, when user bob logs into the SCS, he will automatically start PPP and run the site
dialin_users.
To ensure that the user is not left at the Local> prompt after the forced command finishes executing, the
string ";logout" may be added.

11.5.7 Restricting Multiple Authenticated Logins

The Set/Define Authentication Unique Enabled command can be used to prevent a single PPP or Local
mode user from making multiple authenticated connections to the SCS.
For example, imagine that ports 1 through 8 have authentication enabled, but ports 9 through 16 do not. If
user george connects to port 2 and enters the correct password, he will be permitted to login. If, while george
is connected to port2, another user tries to log into port3 using george as his username, he will be rejected.
Figure 11-40: Locking and Unlocking a Port
Figure 11-41: Forcing User to Start a Particular Site
11-21
