PPP
Enable PPP CHAP and/or PAP authentication on the ports.
C
Local>> DEFINE PORT 1-4 PPP CHAP REMOTE
Local>> DEFINE PORT 1-4 PPP PAP REMOTE
Create a site to receive the multilink traffic.
2
The site's name must match that of the incoming multilink user (see Figure 7-11).
Local>> DEFINE SITE "sidney"
Configure site authentication.
3
A local authentication password will be needed (it should match the incoming site's remote password,
see Figure 7-11), and CHAP and/or PAP authentication should be enabled.
Local>> DEFINE SITE sidney AUTHENTICATION LOCAL "k0ala"
Use the same authentication protocol on the receiving SCS as on the calling SCS.
Note:

7.5 Restoring Default PPP Settings

To restore a port to its default PPP settings, enter the Purge Port PPP command.
Local>> PURGE PORT 2 PPP

7.6 Pocket PC PPP Support

To enable or disable client/server negotiation when starting a PPP connection with a PocketPC type device,
use the Set/Define Ports PocketPC command.
7.7

Character Mode Sites

The SCS allows you to create a character mode site. A character mode site is treated as a normal site that
does not run a serial protocol. The site still allows modems to be dialed, and can have a chat script and other
functions, but once the site is up, it does not run PPP. The character mode site is normally used to associate
an IP address with a particular serial port or to control an external device using a chat script.
To create a character mode site, use the Set/Define Site <sitename> Protocol None and Set/Define Site
<sitename> IP Remoteaddr <ip_address> commands and then create a host route that points to it with the
Set/Define IP Route <ip_address> Site <sitename> command. The <ip_address> must be on the same IP
subnet as the SCS itself. To make a text mode connection to the serial port, Telnet to <ip_address.
Figure 7-13: Enabling PPP Authentication
Figure 7-14: Creating the Receiving Site
Figure 7-15: Configuring Site Authentication
Figure 7-16: Restoring Default PPP Settings
7-7
Restoring Default PPP Settings
