Lantronix SCS Reference Manual page 364

Command Reference Security Commands
Requires privileged user status.
Parameters Primary
Specifies the first database or server to be checked. A specific address may be
set with the address parameter, or the None parameter may be used to indicate
that the database or file will not be used.
Secondary
If the SCS fails to authenticate the user using the primary database or server
(due to network failure, server failure, missing or incorrect username/
password), the secondary database or server will be checked. A specific
address may be set with the address parameter, or the None parameter may be
used to indicate that the server will not be used.
If the user cannot be authenticated using the secondary database or server, the
database or server with the next precedence level will be checked. If all
precedence levels fail to authenticate the user, the user is prevented from
logging in.
address
A text host name (if a DNS is available for name resolution) or an IP address
in standard numeric format (for example, 192.23.71.49).
None
Clears the current server address.
Precedence
Sets the precedence in which this database or server is checked. The
precedence number must be specified using the prec_num parameter.
prec_num
A precedence number between 1and 6.
Encryption
SecurID (SID) or DES encryption will be used for authentication.
SID
Enables use of SecurID encryption.
DES
Enables use of DES encryption.
Maxtries
Specifies the maximum number of times the SCS will attempt to contact the
SecurID server. Must be used in conjunction with the tries parameter.
tries
An integer between 1 and 255, inclusive.
Port
Specifies the UDP/IP port number used to communicate with the primary and
secondary SecurID servers. Must be used in conjunction with the PortNum
parameter.
12-160
