Configuring The Receiving Scs - Lantronix SCS Reference Manual

PPP
Specify the initial and maximum bandwidths.
A
The maximum bandwidth should not exceed the sum of the bandwidths for all of the ports.
Local>> DEFINE SITE irvine BANDWIDTH INITIAL 2800
Local>> DEFINE SITE irvine BANDWIDTH MAXIMUM 11500
For more information about site bandwidth settings and how to fine-tune them, see Configuring
Bandwidth Allocated to Sites on page 5-6.
B Specify when to add and remove bandwidth from a connection.
In the following example, the bandwidth should remain between 40% and 90% of the maximum
value, 11500 bytes per second. The bandwidth will be measured every 60 seconds and compared
to the add and remove values to see if an adjustment is necessary.
Local>> DEFINE SITE irvine BANDWIDTH ADD 90
Local>> DEFINE SITE irvine BANDWIDTH REMOVE 40
Local>> DEFINE SITE irvine BANDWIDTH PERIOD 60
Configure site authentication.
5
All of the ports raised for a multilink connection should be added to the connection and authenticated
together. A username and remote authentication password will be needed, and CHAP and/or PAP
authentication should be enabled.
Local>> DEFINE SITE irvine AUTHENTICATION USERNAME "sidney"
Local>> DEFINE SITE irvine AUTHENTICATION REMOTE "k0ala"
Local>> DEFINE SITE irvine AUTHENTICATION CHAP ENABLED
Local>> DEFINE SITE irvine AUTHENTICATION PAP ENABLED

7.4.2 Configuring the Receiving SCS

Configure the ports that will be used for the multilink connection.
1
A Enable Multilink PPP on all ports that will be used.
Local>> DEFINE PORT 1-4 PPP MULTILINK ENABLED
Ensure that the telephone numbers of the modems attached to the receiving ports match those
B
configured in the calling site.
Figure 7-9: Configuring Initial and Maximum Bandwidths
Figure 7-10: Configuring Site Bandwidth Settings
Figure 7-11: Configuring Site Authentication
Figure 7-12: Enabling Multilink PPP
7-6
Multilink PPP
