Supported RADIUS Attributes
D.1.2 Access-Accept
The SCS interprets reply attributes based on the Service-Type received in the Access-Accept. Supported
service types include:
Login
Framed
Callback-Login
Callback-Framed
Prompt
See RADIUS on page 11-14 for the differences between the login and prompt
Note:
service types and how they are handled by the SCS.
The table below shows the additional attributes that can be used in Access-Accept packets sent by the
RADIUS server. Items marked with plus signs (+) are only valid when the Service-Type is Login or
Callback-Login. Items marked with asterisks (*) are only valid when the Service-Type is Framed or
Callback-Framed.
Attribute
Framed-Protocol*
Framed-IP-Address*
Framed-Routing*
Filter-ID*
Framed-MTU*
Framed-Compression*
Login-IP-Host+
Login-Service+
Login-TCP-Port+
Reply-Message
Session-Timeout
Idle-Timeout
The user is connected to a specific host.
A PPP or SLIP connection is started.
The user is disconnected and called back, then connected to a host.
The user is disconnected and called back, then begins a PPP/SLIP connection.
The user is provided with a command line prompt on the SCS from which it is
possible to enter privileged commands.
Table D-1: Access-Accept Attributes
Supported Values (if any)
PPP
SLIP
See Framed-IP-Address on page D-3
Send
Listen
Send & Listen
None
See Filter-ID, page -3
None
Van-Jacobson TCP/IP Header Compression
See Login-IP-Host on page D-3
Telnet
Rlogin
TCP-Clear (raw TCP connection)
D-2

Access-Accept
