Lan To Lan-Bidirectional (Symmetric) Calling - Lantronix SCS Reference Manual

Basic Remote Networking
IP users in a remote office in Dallas must connect to IP network 192.0.1.0, which is located at the
company headquarters in Seattle.
The SCS in Seattle never calls Dallas.
The SCS in Seattle must support character mode users as well as the SCS in Dallas.
After 60 seconds of idle time, the connection between Dallas and Seattle should be timed out.
The SCS in Dallas must be configured for outgoing LAN to LAN connections.
Local>> DEFINE PORT 2 ACCESS DYNAMIC
Local>> DEFINE PORT 2 MODEM ENABLED
Local>> LIST MODEM
Local>> DEFINE PORT 2 MODEM TYPE 1
Local>> DEFINE PORT 2 MODEM SPEAKER DISABLED
Local>> DEFINE PORT 2 AUTHENTICATE ENABLED
Local>>
Local>> DEFINE SITE SEATTLE AUTHENTICATION USERNAME "dallas"
Local>> DEFINE SITE SEATTLE AUTHENTICATION REMOTE "xyz"
Local>> DEFINE SITE SEATTLE AUTHENTICATION CHAP ENABLED
Local>> DEFINE SITE SEATTLE IDLE 60
Local>> DEFINE SITE SEATTLE PORT 2
Local>> DEFINE SITE SEATTLE TELEPHONE 2065551234
Local>>
Local>> DEFINE IP ROUTE 192.0.1.0 SITE SEATTLE 2
Local>>
Local>> INITIALIZE SERVER DELAY 0
The Initialize Server Delay 0 command will reboot the SCS; when the unit has rebooted, changes made
with the Define commands will be in effect.
The SCS in Seattle must then be configured using the following commands:
Local>> DEFINE PORT 2 MODEM ENABLED
Local>> LIST MODEM
Local>> DEFINE PORT 2 MODEM TYPE 1
Local>> DEFINE PORT 2 MODEM SPEAKER DISABLED
Local>> DEFINE PORT 2 PPPDETECT ENABLED
Local>> DEFINE PORT 2 PPP CHAP REMOTE
Local>> DEFINE PORT 2 AUTHENTICATE ENABLED
Local>> LOGOUT PORT 2
Local>>
Local>> DEFINE SITE dallas AUTHENTICATION LOCAL "xyz"
Local>> DEFINE IP ROUTING ENABLED
Local>>
Local>> INITIALIZE SERVER DELAY 0
4.8.2 LAN to LAN—Bidirectional (Symmetric) Calling
An SCS in a remote office in Dallas must be able to call an SCS at the company headquarters in Seattle.
This LAN to LAN connection must meet the following criteria:
Figure 4-35: Dallas SCS Configuration
Figure 4-36: Seattle SCS Configuration
4-22
Examples
