B: Show 802.11 Errors

B.1 Introduction
This appendix applies only to the SCS200.
Note:
When you enter the Show 80211 command without any other parameters, the resulting screen includes a
field for errors. The "Errors:" field displays two eight-digit numbers, separated by a comma. These
numbers are a 64-bit wide bitfield of error bits, each one indicating whether or not the given error has
occurred at least once.
For example, suppose you're using an SCS200 with a ZoomAir card in Infrastructure mode. After having
been running for a long time, your Access Point loses power in the middle of sending a fragmented packet
to the SCS. If you entered the Show 80211 command, you might see a screen resembling the following:
Local>> SHOW 80211
802.11 Support:
Network Type:
Use MAC address from: SCS (00-80-a3-30-ee-31)
ESS ID:
Regulatory Region:
DS Channel:
RTS Threshold:
Fragmentation Threshold: 2346
Card Present:
Status:
Errors:
Card Firmware Revision: 2.01
The Errors bitfield is zeroed each time you issue either a Zero command or a Set 802.11 Reset command
at the Local> prompt.
The Errors bitfield is zeroed each time you issue either a Zero command or a Change 802.11 Reset
command at the Local> prompt.
B.2 Error Bits
B.2.1 Leftmost Number
80000000
40000000
20000000
Figure B-1: Example of Error Bits
Active
Infrastructure
(none set)
FCC/USA
Any
3000
Zoom Air 4000
Scanning
08020002,00000920
An authentication or association sequence timed out. An expected reply from
the AP was not received within the required time window.
Internal error.
Internal error.
