Getting Started
The following parameters should be configured only if you are using the SCS for 802.11 wireless Ethernet
networking and plan to use a wireless LAN PC card in one of the PC card slots. Users in countries other
than the United States must set the Region appropriately before using 802.11.
Not all configuration options will be available on all 802.11 cards. If you try to enter an option that is not
supported by your card, you will receive an Error message.
Any time you enable or disable 802.11 networking, you must reboot the SCS before the change takes effect.
Any other changes you request with the Set/Define 80211 commands will not take place until you have
entered the Set 80211 Reset command. You can enter the Show IP Counters command to see the current
802.11 settings.
To use the web browser interface to configure 802.11 settings, select the 802.11 link under the Advanced
Settings section.
2.4.5.1 802.11 Terms
The following acronyms are used in this section:
AP
If you are using an AP and WEP is not enabled, set the AP to accept Open System
Note:
Authentication. If WEP is enabled, set the AP to Shared Key Authentication. For
more information about WEP, see the definition below.
Access Point, a device that relays communications between one or more
wireless devices and possibly other devices on a network. APs are usually
connected to a physical network.
