Console Server Features
The List Email command can be used to show the emailsite configurations for one or more emailsites.
If network logging is enabled (Set/Define Logging Network Enabled), any errors that occur during email
notification are stored in the system log. System logging is discussed in Chapter 11, Security.

3.4 Configuring Menu Mode

When a port is in menu mode, users who log into the port will be presented with a list of menu options. Their
choices are limited to those displayed in the menu, as they will not be permitted to enter text commands.
Lantronix Console Server
1) Cisco Router
2) Sun Server
3) Linux Server
Enter Selection:
Menus can be configured one of two ways: by entering title and item entries individually with the web
browser interface or at the command line, or by creating a menu configuration file.
To enable menu mode on a particular port, use the Set/Define Ports Menu command.
Local>> DEFINE PORT 2 MENU ENABLED
To display the current menu, use the Show/Monitor/List Menu command. If you are using a menu
configuration file, this command will not work—you must view that file to see the menus.

3.4.1 Menu Configuration at the Command Line

Use the Set/Define Menu command to create entries for your menu. For each menu entry, specify the
option's numbered position in the table, the entry description that will be displayed in the menu, and the
actual command invoked when the user chooses that option. Enclose option and command names in
quotes.
Local>> DEFINE MENU 2 "Sun Server" "CONNECT LOCAL PORT_2"
It is a good idea to add a command to the menu that allows the user to log out of the server. The Exit
command only works in menu mode. It allows users to return to the Local> prompt on the SCS on which
the menu was configured. It is helpful to include this command in your menus until you have fully tested
them—otherwise there is no way for users on menu mode ports to return to the Local> prompt.
Local>> DEFINE MENU 5 "Exit" "Logout"
Figure 3-5: Sample Menu
4) Local> Prompt
5) Logout
6)
Figure 3-6: Enabling Menu Mode on a Port
Figure 3-7: Adding a Command Entry
Figure 3-8: Adding a Logout Command
3-4
Configuring Menu Mode
