Register Summary: General-Purpose Timers - Analog Devices ADuCM355 Hardware Reference Manual

UG-1262

REGISTER SUMMARY: GENERAL-PURPOSE TIMERS

Table 342. Timer Register Summary
Address Name
0x40000000 GPT0_LOAD
0x40000004 GPT0_CURCNT
0x40000008 GPT0_CTL
0x4000000C GPT0_CLRINT
0x40000010 GPT0_CAPTURE
0x40000014 GPT0_ALOAD
0x40000018 GPT0_ACURCNT
0x4000001C GPT0_STAT
0x40000400 GPT1_LOAD
0x40000404 GPT1_CURCNT
0x40000408 GPT1_CTL
0x4000040C GPT1_CLRINT
0x40000410 GPT1_CAPTURE
0x40000414 GPT1_ALOAD
0x40000418 GPT1_ACURCNT
0x4000041C GPT1_STAT
0x40000800 GPT2_LOAD
0x40000804 GPT2_CURCNT
0x40000808 GPT2_CTL
0x4000080C GPT2_CLRINT
0x40000810 GPT2_CAPTURE
0x40000814 GPT2_ALOAD
0x40000818 GPT2_ACURCNT
0x4000081C GPT2_STAT
ADuCM355
Description
16-bit synchronous load value
16-bit timer synchronous value
Control
Clear interrupt
Capture
16-bit asynchronous load value
16-bit timer asynchronous value
Status
16-bit synchronous load value
16-bit timer synchronous value
Control
Clear interrupt
Capture
16-bit asynchronous load value
16-bit timer asynchronous value
Status
16-bit synchronous load value
16-bit timer synchronous value
Control
Clear interrupt
Capture
16-bit asynchronous load value
16-bit timer asynchronous value
Status
Rev. B | Page 270 of 312
Hardware Reference Manual
Reset
0x0000
0x0000
0x000A
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x000A
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x000A
0x0000
0x0000
0x0000
0x0000
0x0000
Access
R/W
R
R/W
W
R
R/W
R
R
R/W
R
R/W
W
R
R/W
R
R
R/W
R
R/W
W
R
R/W
R
R
